Dry-Type Transformers

Cast resin and VPI dry-type transformers for indoor commercial, industrial, and marine applications. Low maintenance, fire-safe, and suitable for confined spaces.

30 kVA – 2,500 kVA
1000 / 2000 kVA Spec Sheet

Matched Products

104

Voltage Class
Rated Capacity
IEC 60076-11 & UL 1562 Standard

Cast Resin & VPI Dry-Type Transformers (30 kVA – 2500 kVA, Class F & H Insulation)

Engineered for indoor substations, commercial high-rise towers, hospitals, and offshore platforms where fire safety and zero toxic emissions are critical. Non-flammable, self-extinguishing, and virtually maintenance-free.

F1 Fire-Safe & Self-Extinguishing

Pure epoxy resin solid encapsulation prevents combustion; certified to IEC 60076-11 F1 flammability and C2 climate class.

Ultra-Low Partial Discharge < 5 pC

Thin-layer vacuum casting guarantees zero air bubble entrapment, preventing insulation breakdown over decades.

PT100 Temperature Monitoring

Embedded PT100 sensors across all 3 phases connect to an intelligent digital temperature controller with 4-20mA/RS485 alarm outputs.

+40% Forced Air Capacity (AF)

Automatic cross-flow cooling fans increase peak transformer capacity by up to 40% during emergency overloads.

Dry-Type Series Matrix

Series Capacity Insulation Typical Use
SCB10 Series 30–2500 kVA Class F (155°C) Commercial & industrial
SCB13 Series 50–2500 kVA Class F (155°C) -15% Loss, data centers
SCB14 / 18 100–3150 kVA Class H (180°C) EcoDesign Tier 2 standard
SG(B) VPI 50–2000 kVA Class H (Nomex) Marine & mining traction
E2/C2/F1 Certified Request Dry Quote
